1 F8206501P Output Board VCMP Assembly
2 F140249 Battery Backup Wire Harness Connects the output board cca to the battery adapter board; Models through
5/14/00
3 F634175 Control Module Cover
4 F140605 Cable Tie
5 505281 Disconnect Power Warning Label Warning: High Voltage
6 F350109 Fuse 1/2 Amp; Fast
6 F350110 Fuse 1 Amp; Slo
6 F350108 Fuse 1/8 Amp; Slo
7 F0350312-10 Fuse Holder Uses F350110 Fuse (1 Amp) and F350117 Fuse (2 Amp)
8 F430916 Screw
9 F180506 Standoff
10 F633322 Fuse Terminal Mounting Bracket
11 F430982 Screw
12 F290115 Thermostat
13 F430928 Screw
14 F330227 Flange Relay 120 Volt
15 F431113 Washer
16 F431022 Nut
17 F140768 Terminal
18 F140909 Insulator Bushing
19 F350110 Fuse 1 Amp
20 F0632387-01P Door Lock CCA
21 F370225P Capacitor
22 F140612P Capacitor Mounting Clamp
23 F430910 Screw
24 F170128 Sponge Rubber Order 2 feet
25 F632084 Coin Guide Assembly Single drop
25 F200002503 Coin Guide Assembly Dual drop
26 N/A Control Box Assembly Models through 10/31/99
26 F633380-1 Control Box Assembly Models starting 11/1/99 through 4/22/01
26 F0635628-01 Control Box Assembly Models starting 4/23/01
26 N/A Control Box Assembly CE models starting 10/31/99
27 F431210 Pop Rivet
28 F430174 Screw
29 F631920 Water Level Switch Bracket
30 F0340351-10P Water Level Switch
31 F180501 Standoff
32 F370529P Battery Adapter Board Models through 5/14/00
33 F430231 Nut
34 F191101 Battery Models through 5/14/00
35 F200025200P Door Lock Time Delay
36 F140247 Ribbon Cable Connects the output board to the microprocessor
N/A = Part no longer available
|
|
|
|
